Introduction
By 2030, the global semiconductor market is projected to reach a staggering $1 trillion, driven by demand for AI processors, 5G infrastructure, electric vehicles, and advanced consumer electronics. But behind the race for smaller, faster, and more efficient chips lies a geopolitical scramble to control the supply chain. In this high-stakes arena, India has launched an ambitious $10 billion India’s Semiconductor Mission — a bold strategy to transform itself from a chip importer into a global manufacturing powerhouse.
With 10 new mega projects spanning six states, India is partnering with top tech players to build fabs, OSAT facilities, and design hubs that could reshape the global chip industry and reduce dependence on traditional manufacturing giants like Taiwan, South Korea, and China
5 Key Takeaways at a Glance
10 projects approved across Odisha, Andhra Pradesh, Punjab, Uttar Pradesh, Gujarat, and Assam.
$10B+ total investment with major global technology partners from the UK, Taiwan, Japan, Korea, and the US.
Focus on SiC fabs, ATMP, OSAT, glass substrates, display driver ICs, and logic chip manufacturing.
Projects to create thousands of high-skill jobs and significantly cut import dependency.
First outputs expected from mid-2025, with large-scale production by 2027.
1. SiCSem Pvt. Ltd. – Bhubaneswar, Odisha
India’s first commercial Silicon Carbide (SiC) fab, in partnership with UK’s Clas-SiC Wafer Fab Ltd.
- Capacity: 60,000 wafers/year & 96M packaged units.
- Applications: Electric vehicles (EVs), solar inverters, fast chargers, railways, defense electronics, and data centers.
- Importance: SiC chips operate at higher voltages and temperatures, delivering greater energy efficiency — critical for next-gen power electronics.
2. 3D Glass Solutions Inc. – Bhubaneswar, Odisha
An advanced packaging and embedded glass substrate facility, enabling 3D Heterogeneous Integration.
- Capacity: 69,600 glass substrates, 50M assembled units, 13,200 integration modules/year.
- Applications: AI accelerators, RF, photonics, high-performance computing, and co-packaged optics.
- Edge: Glass substrates allow high-speed signal transmission with minimal power loss, ideal for advanced AI chips.
3. ASIP Technologies – Andhra Pradesh
Joint venture with APACT Co. Ltd., Korea to produce 96M units annually.
- Applications: Mobile phones, set-top boxes, automotive electronics, IoT devices.
- Focus: System-in-Package (SiP) technology integrates multiple chips into one package, reducing size and improving performance for consumer electronics.
4. Continental Device India Ltd. (CDIL) – Mohali, Punjab
Expansion into manufacturing MOSFETs, IGBTs, Schottky diodes, and silicon & SiC-based transistors.
- Capacity: 158M units/year.
- Markets: EV powertrains, renewable energy, industrial automation, telecom infrastructure.
- Significance: Strengthens India’s domestic supply for critical discrete components.
/techovedas.com/4-powerful-schemes-propelling-indias-semiconductor-revolution
5. HCL-Foxconn JV – Near Jewar Airport, Uttar Pradesh
A display driver IC fab targeting smartphone, TV, and automotive display markets.
- Capacity: 20,000 wafers/month & 36M chips/year.
- Timeline: Commercial output by 2027.
- Impact: Reduces dependence on imports from Taiwan and South Korea for display electronics.
6. Tata Electronics + PSMC Fab – Dholera, Gujarat
Large-scale logic chip wafer fabrication facility in partnership with Taiwan’s PSMC.
- Capacity: 50,000 wafers/month.
- First Batch: Expected December 2026.
- Importance: Key step in moving India into high-end logic semiconductor manufacturing.
https://medium.com/p/76fc9e36cce3
7. Micron Technology ATMP OSAT – Sanand, Gujarat
A $2.75B investment in assembly, testing, marking, and packaging.
- Timeline: First chips mid-2025.
- Role: Positions India as a hub for memory chip packaging, critical for servers, smartphones, and AI hardware.
8. Tata Semiconductor (ATMP) – Morigaon, Assam
India’s first indigenous large-scale ATMP facility.
- Capacity: 48M chips/day.
- Focus: Consumer electronics, automotive systems, industrial electronics.
- Impact: Strengthens domestic manufacturing of finished semiconductor products.
9. CG Power ATMP – Sanand, Gujarat
Joint venture with Japan’s Renesas Electronics and Thailand’s Stars Microelectronics.
- Capacity: 15M chips/day.
- Markets: Industrial automation, automotive electronics, consumer devices.
10. Kaynes Semicon OSAT – Sanand, Gujarat
Outsourced Semiconductor Assembly and Testing (OSAT) plant.
- Capacity: 6.3M chips/day.
- Target: Global OSAT demand, reducing reliance on overseas packaging hubs.
Why These Projects Are a Big Deal for India
By 2030, the global chip market will hit $1 trillion — and India’s Semiconductor Mission is charging ahead with a $10B plan. From fabs to OSAT units, 10 mega projects across six states aim to turn India into a global chip hub, cut its 90% import dependence on Taiwan, South Korea, China, and the US, and reshape the global supply chain.
- Domestic chipmaking capacity will expand across materials, logic chips, and power semiconductors.
- Supply chain resilience improves, shielding India from geopolitical disruptions.
- Employment generation in high-tech manufacturing accelerates, boosting skill development.
- R&D opportunities grow, fostering local innovation in AI, EVs, and defense electronics.
Challenges Ahead
Despite the momentum, the semiconductor mission faces hurdles:
- Talent shortage in specialized chip manufacturing roles.
- Technology transfer complexities from foreign partners.
- Infrastructure readiness for utilities, water, and cleanroom environments.
- Global competition from established chipmaking nations.
Conclusion
If executed on schedule, India’s semiconductor mission see its first large-scale semiconductor outputs by 2025 and full-scale chip production by 2027. This will position the country as a regional alternative to East Asian semiconductor dominance, opening up opportunities in global supply chains.
As the Semiconductor Investment Game goes dicey, trust @Techovedas for any Semiconductor Hassles!
